Name: 1.5 mm Suttner Nozzle for Adjustable Spray Lance
SKU: 9595594441011
Availability: InStock

Description

1.5 mm Suttner Nozzle for Adjustable Spray Lance (#110169).

Hole Dia (mm)	Performances	Pressure
200 PSI	350 PSI	500 PSI	600 PSI	650 PSI	700 PSI	850 PSI
Cone	Straight	Cone	Straight	Cone	Straight	Cone	Straight	Cone	Straight	Cone	Straight	Cone	Straight
1.2	Capacity US/GPM Spray Angle Max Throw Ft	0.89 22° 8.6′	0.94 – 17.8′	1.11 22° 9.69′	1.2 – 20′	1.25 24° 10.5′	1.43 – 21.4	1.37 24° 11.3′	1.57 – 23.9′	1.43 26° 11.3	1.64 – 25′	1.53 26° 11.6′	1.76 – 25.8′	1.63 26° 12.1′	1.84 – 29.4′
1.5	Capacity US/GPM Spray Angle Max Throw Ft	1.14 25° 9.2′	1.26 – 21.5′	1.48 28° 10.3′	1.7 – 25.2′	1.8 28° 11.2′	2 – 28	1.9 28° 12.1′	2.2 – 31.8′	2 30° 12.1′	2.3 – 32′	2.1 30° 12.3′	2.4 – 32.3′	2.2 30° 13.1′	2.5 – 34.3′
2.0	Capacity US/GPM Spray Angle Max Throw Ft	1.7 30° 10.8′	2.2 – 26.1′	2.1 32° 12.3′	3.1 – 30.7′	2.7 35° 13.2′	3.6 – 34.6′	3 35° 14.9′	4 – 38.1′	3.1 35° 15.3′	4.1 – 38.3′	3.3 37° 15.5′	4.2 – 38.8′	3.6 37° 16.7′	4.5 – 42.5′
2.3	Capacity US/GPM Spray Angle Max Throw Ft	2.1 40° 11.4′	2.7 – 29′	2.7 40° 12.9′	3.7 – 33.9′	3.4 42° 14.8′	4.5 – 37.9′	3.8 42° 16.6′	4.9 – 41.5′	3.8 45° 17.0′	5 – 41.7′	3.9 45° 17.7′	5.1 – 42.0′	4.2 45° 19′	5.8 – 45.7′
2.5	Capacity US/GPM Spray Angle Max Throw Ft	2.3 30° 10.8′	3.2 – 26.1′	3 32° 12.3′	4.3 – 30.7′	3.7 35° 13.2′	5.1 – 34.6′	4 35° 14.9′	5.9 – 38.1′	4.1 35° 15.3′	5.9 – 38.3′	4.3 37° 15.5′	6 – 38.8′	4.9 37° 16.7′	6.8 – 42.5′
3.0	Capacity US/GPM Spray Angle Max Throw Ft	2.9 48° 11.7′	4.6 – 29.2′	3.7 48° 12.9′	6.3 – 33.9′	4.8 52° 13.8′	7.5 – 36.2′	5.2 52° 15.6′	8.4 – 40.8′	5.3 55° 16.0′	8.5 – 40.7′	5.4 55° 16.2′	8.6 – 42′	6 55° 17′	9.6 – 44.1′
3.5	Capacity US/GPM Spray Angle Max Throw Ft	5.8 40° 13.6′	6 – 36.2′	7.9 40° 19′	8.2 – 41.2′	9.6 40° 22.6′	9.9 – 45.3′	10.7 40° 25.5′	11.1 – 50′	11 40° 25.5′	11.3 – 51′	11.2 45° 27′	11.6 – 51.5′	12.4 45° 28.8′	12.8 – 54′
7.0	Capacity US/GPM Spray Angle Max Throw Ft	11.5 70° 21.1′	13.5 – 46.8′	15.6 80° 25.3′	18.4 – 57′	18.8 80° 30.7′	22.2 – 63′	21 75° 37.4′	25 – 70′	21.5 75° 37.4′	25.4 – 71′	22 75° 38′	26 – 72′	24.4 75° 38′	29 – 77′
